Database 1 - Systems, Models, and SQL

Welcome - pull up a chair. This first database blog begins with a question that sounds almost too simple: why not keep data in ordinary files? A file can certainly store names, courses, salaries, or transactions. The difficulty begins when several applications must share those facts, several users update them at the same time, and the system must remain correct after a crash.

That is the setting in which a database management system becomes useful. We will first understand the problem a DBMS solves, then follow data through the four design phases, and finally build the relational vocabulary needed for keys and SQL.

Course snapshot. COMS W4111 uses PostgreSQL. Course materials, the syllabus, and assignment portals are hosted at dbcourse.app and require the Columbia Google account. For this meeting, the course quiz and HW1 opening were scheduled for September 17, 2026. The teaching team is Prof. Oktie Hassanzadeh and four TAs; asking for help early matters because later design decisions build on the vocabulary introduced here.

What a DBMS Does

A database management system (DBMS) is software that manages interrelated data and mediates between applications and physical storage. Applications ask the DBMS to define, retrieve, modify, protect, and recover data; they do not manipulate disk blocks directly.

This division of responsibility gives us several services at once:

Data definition: schemas declare which tables, attributes, and constraints exist.
Data manipulation: a common query language reads and changes data.
Integrity: shared rules are checked for every application.
Concurrency: transactions coordinate operations from simultaneous users.
Recovery: logs and recovery protocols restore a valid state after failure.
Administration and security: access can be controlled at a finer level than an entire file.

The important word is system. A database is not merely a collection of tables; the DBMS is the machinery that keeps those tables meaningful while the surrounding world changes.

Why Plain Files Break Down

Suppose a university stores student contact information in one advising file, one billing file, and one course-registration file. The same email address now appears three times. If a student changes it and only two applications update their copies, the university has three files but no single trustworthy answer.

That example exposes the first failure mode, but not the last:

Redundancy and inconsistency. Repeated facts drift apart when updates do not reach every copy.
Difficult access. Every new question requires another parser or application program.
Integrity and atomicity problems. Business rules are duplicated in application code, and a crash halfway through a multi-step update can leave only part of the change recorded.
Concurrent-access anomalies. Two operations can read the same old value and overwrite one another. Two simultaneous withdrawals, for example, may both approve themselves against the same balance.
Security problems. File permissions are usually all-or-nothing; they do not naturally express that one role may read a table but not a sensitive column or particular rows.

Concern	Files plus application code	DBMS responsibility
Schema	Hidden inside programs	Declared and enforced
New question	Write another program	Write a declarative query
Integrity	Reimplemented by each app	Declared once and checked for all writes
Concurrency	Ad hoc locking	Transaction-based isolation
Crash recovery	Manual or unreliable	Automated, log-based recovery
Access control	Usually file-level	Table-, column-, and row-level policies

Data Independence

The deeper benefit is data independence. An application states what information it needs without specifying the exact disk blocks, indexes, or join algorithm used to find it. The DBMS may add an index, reorganize pages, or choose a different execution plan without forcing the application query to change.

Key idea: separating the logical request from the physical retrieval strategy lets a database evolve internally while preserving the interface seen by applications.

Data Categories and Models

Database architecture depends heavily on variety, one of the familiar five Vs of data: volume, velocity, variety, veracity, and value. Variety asks how consistently records share a structure.

Structured data follows a fixed schema chosen before data arrives. A relational table with a known set of columns is the standard example.
Semi-structured data carries structure with each record. JSON and XML documents can have named fields even when every record is not identical.
Unstructured data has no internal structure that an ordinary database query can directly use, such as free text, images, or audio.

A data model is a collection of conceptual tools for describing data, relationships, semantics, and constraints. Two models are central here:

The entity-relationship model is a design language. It helps us reason about the domain before committing to tables.
The relational model represents data as relations, implemented by relational database systems.

An ER diagram is therefore not usually the final production database. It is a conceptual bridge from a real domain to a relational schema.

The Database Design Pipeline

A reliable database is designed in stages because each stage answers a different question.

Requirements Analysis

First, identify what users need to store and what questions or operations the system must support. The output is a characterization of the data needs, not yet a table design.

Conceptual Design

Next, identify entities, relationships, attributes, and constraints. The output is a model-independent ER diagram that explains the domain without committing to PostgreSQL details.

Logical Design

The conceptual model is translated into relations and attributes. This phase produces the relational schema and includes two distinct decisions:

Business decision: which facts about the organization should be recorded at all?
Computer-science decision: how should those facts be grouped into tables so that redundancy and anomalies are controlled? This is where normalization enters.

Physical Design

Only after the logical structure is stable do we choose indexes, partitioning, storage layouts, and other physical details. These choices should respond to measured workloads rather than guesses.

Design order: requirements tell us what matters; the conceptual model tells us what exists; the logical model tells us how facts are represented; physical design tells us how the chosen representation will run efficiently.

Relations, Tuples, and Domains

In Ted Codd’s relational model, information is represented by mathematical relations.

A relation is represented as a table.
A row is a tuple.
A column is an attribute.
An attribute’s domain is the set of values it is permitted to take.
A schema describes the logical structure, while an instance is the collection of tuples present at one particular moment.

For example,

$'_' allowed only in math mode \text{instructor}(\text{ID},\text{name},\text{dept_name},\text{salary})$

is a schema. The current instructor rows form one instance of that schema.

Atomic Domains

An attribute should contain an atomic value: one value at the level at which the database needs to query it. If a single column stores Ferguson, Donald, F, every query that needs only the family name must parse a formatting convention. Likewise, packing a department and course number into COMSW4111 makes both validation and searching harder.

Atomic does not mean “physically indivisible.” It means the value is not treated as a bundle of separately meaningful fields by this database design.

Relations Are Unordered

A relation is an unordered set of tuples. A table display may happen to look sorted because of an index or insertion history, but that order is not part of the relational result. If order matters, a query must request it explicitly.

Keys and Referential Integrity

Keys express identity and connect relations.

A superkey is any attribute set that uniquely identifies every tuple in every legal instance of relation .
A candidate key is a minimal superkey: removing any attribute would destroy uniqueness.
A primary key is the candidate key selected as the relation’s principal identifier.
A foreign key is an attribute set in one relation whose non-NULL values must match a candidate or primary key in another relation.

The foreign-key rule is referential integrity. It prevents a registration row, for example, from referring to a student who does not exist.

Foreign keys are checked on INSERT, UPDATE, and DELETE. They may be NULL when the design permits the absence of a reference. When a referenced row is deleted, the schema must choose a policy:

Restrict or reject: refuse the deletion while referencing rows remain.
Cascade: delete the referencing rows automatically.
Set NULL: preserve those rows but remove the reference.

Natural and Surrogate Keys

A natural key originates in the domain, such as an email address. It is descriptive but may change. A surrogate key is a system-assigned identifier, such as a UNI or CUID. It carries little business meaning but can remain stable.

Primary keys should usually be immutable. A changing key forces updates through every foreign key that refers to it, whereas an immutable surrogate isolates identity from changing descriptive facts.

Declarative SQL

SQL is a declarative language: we describe the desired result, not the sequence of disk and memory operations used to produce it. PostgreSQL’s query optimizer examines statistics, relation sizes, indexes, and available algorithms to choose an execution plan.

A basic single-table query has three main clauses:

SELECT attribute_list
FROM relation
WHERE tuple_predicate;

SELECT chooses output attributes, FROM identifies the input relation, and WHERE keeps only tuples satisfying the predicate.

Duplicates and Ordering

Unlike mathematical relational algebra, SQL keeps duplicate result rows by default. Use SELECT DISTINCT when duplicates must be removed.

SQL also makes no default ordering promise. Use an explicit clause such as:

ORDER BY salary DESC;

NULL and Three-Valued Logic

NULL represents an unknown or inapplicable value. It is neither zero nor an empty string. A comparison involving NULL usually produces UNKNOWN, so SQL predicates use three truth values: TRUE, FALSE, and UNKNOWN.

A WHERE clause keeps a row only when its predicate evaluates to TRUE. Therefore neither grade = NULL nor grade <> 'A' selects a row whose grade is NULL. Test missingness explicitly:

WHERE grade IS NULL

WHERE grade IS NOT NULL

The Foundation We Built

The first meeting gives us a complete conceptual spine. A DBMS replaces fragmented file logic with shared schemas, constraints, transactions, security, and recovery. Requirements become a conceptual model, then a relational schema, and only then a physical implementation. Within that schema, atomic domains give attributes meaning, keys give tuples identity, foreign keys protect relationships, and declarative SQL lets the optimizer choose how to retrieve the requested result.

The next blog moves from this foundation into ER notation, cardinality, relational algebra, and joins.
